Great Planes Yak-55 EP 3D ARF - GPMA1190 - Manual (Page 8)

❏
1. Cut the covering away from the wing in the shaded
area shown. Do this on both the top and the bottom.
❏
2. Glue the wing into the fuselage, making sure that it is
centered and square.
❏
1. Use the included clear tape to hinge the ailerons to the
wing. Tape the top of the hinge first, then fold the aileron up
as far as possible and tape the bottom side.
❏
1. Remove the screws and servo arms from your servos.
Push each screw through the center hole of a servo arm
extender (1 double-sided and 2 single-sided).
Install the Servos
Hinge the Ailerons Join the Wing to the Fuselage
8
