Cabletron Systems EMC38-12 User Manual
Page 33
TWISTED PAIR WIRING TABLES
EMC38-12 USER’S GUIDE
Page B-7
Port 4
Pin
Pin
Pin
B13
Red/Orange
RX+
3 RX+
3 RX+
3 RX+
B14
Orange/Red
RX-
6 RX-
6 RX-
6 RX-
B15
Red/Green
TX+
1 TX+
1 TX+
1 TX-
B16
Green/Red
TX-
2 TX-
2 TX-
2 TX-
Port 3
Pin
Pin
Pin
B9
White/Gray
RX+
3 RX+
3 RX+
3 RX+
B10
Gray/White
RX-
6 RX-
6 RX-
6 RX-
B11
Red/Blue
TX+
11 TX+
1 TX+
1 TX+
B12
Blue/Red
TX-
2 TX-
2 TX-
2 TX-
Port 2
Pin
Pin
Pin
B5
White/Green
RX+
3 RX+
3 RX+
3 RX+
B6
Green/White
RX-
6 RX-
6 RX-
6 RX-
B7
White/Brown
TX+
1 TX+
1 TX+
1 TX+
B8
Brown/White
TX-
2 TX-
2 TX-
2 TX-
Port 1
Pin
Pin
Pin
B1
White/Blue
RX+
3 RX+
3 RX+
3 RX+
B2
Blue/White
RX-
6 RX-
6 RX-
6 RX-
B3
White/Orange
TX+
1 TX+
1 TX+
1 TX+
B4
Orange/White
TX-
2 TX-
2 TX-
2 TX-
Table B-2. Punch Down Block to a 10Base-T Device (Continued)
From Punch Down
Block
To RJ-45
Wallplate
Into
Office
Drop
Into
10Base-T
Device
