(continued from page 4)
·
The stabilizer and wing incidences and engine thrust
angles have been factory-built into this model. However,
some technically-minded modelers may wish to check
these measurements anyway. To view this information
visit the web site at greatplanes.com and click on
“Technical Data.” Due to manufacturing tolerances, which
will have little or no effect on the way your model will fly,
please expect slight deviations between your model and
the published values.
IMPORTANT INFORMATION ABOUT
WORKING WITH FIBERGLASS
If you have never worked with fiberglass there are a few
basic things you should be aware of.
1. When cutting fiberglass, be sure you are cutting the
correct place. Unlike wood, you are not able to go back and
easily fix a mistake.
2. Whenever you are gluing a part to the inside of fiberglass it is
important to roughen the inside surface of the fiberglass with
220-grit sandpaper, then wipe the area with rubbing alcohol.
The molding process leaves a waxy residue that can prevent a
good bond between the glue and the parts being glued.
3. If you do not have a high-speed motor tool such as a Dremel ™
tool you should consider purchasing one or borrowing one from
a fellow modeler. This, combined with a fiberglass cut-off wheel,
will be extremely helpful in the assembly process.
WARNING: The cowl, wheel pants and fuselage included in
this kit are made of fiberglass, the fibers of which may cause
eye, skin and respiratory tract irritation. Never blow into a
part to remove fiberglass dust, as the dust will blow back
into your eyes. Always wear safety goggles, a particle mask
and rubber gloves when grinding, drilling and sanding
fiberglass parts. Vacuum the parts and the work area
thoroughly after working with fiberglass parts.
Replacement parts for the Great Planes Little Toni ARF are
available using the order numbers in the Replacement Parts List
that follows. The fastest, most economical service can be
provided by your hobby dealer or mail-order company. Parts
may also be ordered directly from Hobby Services, but full retail
prices and shipping and handling charges will apply. Illinois and
Nevada residents will also be charged sales tax.
To locate a hobby dealer, visit the Hobbico web site at
www.hobbico.com. Choose "Where to Buy" at the bottom of the
menu on the left side of the page. Follow the instructions
provided on the page to locate a U.S., Canadian or International
dealer. If a hobby shop is not available, replacement parts may
also be ordered from Tower Hobbies at www.towerhobbies.com,
or by calling toll free (800) 637-6050, or from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721. If
ordering via fax, include a Visa or MasterCard number and
expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N Apollo Drive, Suite 1
Champaign IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason, contact
the appropriate Product Support by e-mail or by telephone
at (217) 398-8970.
[email protected]
Replacement Parts List
Order Number Description How to purchase
GPMA2400 . . . . . Wing Kit . . . . . . . . . .Hobby Supplier
GPMA2401 . . . . . Fuse Kit . . . . . . . . . .Hobby Supplier
GPMA2404 . . . . . Tail Set . . . . . . . . . .Hobby Supplier
GPMA2402 . . . . . Cowl . . . . . . . . . . . .Hobby Supplier
GPMA2405 . . . . . Canopy . . . . . . . . . .Hobby Supplier
GPMA2403 . . . . . Landing Gear . . . . . .Hobby Supplier
GPMA2406 . . . . . Wheel Pants . . . . . .Hobby Supplier
GPMA2407 . . . . . Spinner . . . . . . . . . .Hobby Supplier
GPMA2408 . . . . . Decal Sheet . . . . . . .Hobby Supplier
Missing pieces . . . . . Product Support
Instruction manual . . Product Support
Full-size plans . . . . . Not available
Ordering Replacement Parts
1/64" = .4mm
1/32" = .8mm
1/16" = 1.6mm
3/32" = 2.4mm
1/8" = 3.2mm
5/32" = 4mm
3/16" = 4.8mm
1/4" = 6.4mm
3/8" = 9.5mm
1/2" = 12.7mm
5/8" = 15.9mm
3/4" = 19mm
1" = 25.4mm
2" = 50.8mm
3" = 76.2mm
6" = 152.4mm
12" = 304.8mm
15" = 381mm
18" = 457.2mm
21" = 533.4mm
24" = 609.6mm
30" = 762mm
36" = 914.4mm
1" = 25.4mm (conversion factor)
Metric Conversions
6
