Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.
If you have not flown this type of model before, we
recommend that you get the assistance of an experienced
pilot in your R/C club for your first flights. If you’re not a
member of a club, your local hobby shop has information
about clubs in your area whose membership includes
experienced pilots.
In addition to joining an R/C club, we strongly recommend you
join the AMA (Academy of Model Aeronautics). AMA
membership is required to fly at AMA sanctioned clubs. There
are over 2,500 AMA chartered clubs across the country.
Among other benefits, the AMA provides insurance to its
members who fly at sanctioned sites and events. Additionally,
training programs and instructors are available at AMA club
sites to help you get started the right way. Contact the AMA at
the address or toll-free phone number below.
This is the list of hardware and accessories required to
finish the Combat P-51 ARF. Order numbers are provided
in parentheses.
❏
3-Channel radio
❏
3-Channel (or greater) receiver
❏
(3) Micro servos with 34 oz-in of torque
❏
12" [305mm] Servo extension
❏
Switch harness
❏
500mAh Battery
❏
.15 – .25 cu in [2.5 – 4cc] Two-stroke or .30 cu in [5cc]
four-stroke engine
❏
Propellers suitable for your engine.
In addition to common household tools and hobby tools, this
is the “short list” of the most important items required to
build the Combat P-51 ARF.
Great Planes Pro ™ CA and
Epoxy glue are recommended.
❏
1/2 oz. [15g] Thin Pro CA (GPMR6001)
❏
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Pro 6-minute epoxy (GPMR6045)
❏
4-40 Tap and drill set (GPMR8101)
❏
#1 Hobby knife (HCAR0105)
❏
#11 Blades (5-pack, HCAR0211)
❏
2 oz. [57g] Spray CA activator (GPMR6035)
❏
R/C-56 Canopy glue (JOZR5007)
❏
CA applicator tips (HCAR3780)
Here is a list of optional tools mentioned in the manual that
will help you build the Combat P-51 ARF.
❏
Epoxy brushes (6, GPMR8060)
❏
Mixing sticks (50, GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Builder’s Triangle Set (HCAR0480)
❏
Curved-tip canopy scissors for trimming plastic parts
(HCAR0667)
❏
Masking tape (TOPR8018)
❏
Denatured alcohol (for epoxy clean up)
❏
Switch & Charge Jack Mounting set (GPMM1000)
❏
Rotary tool such as Dremel ® Moto-Tool ®
❏
Rotary tool reinforced cut-off wheel (GPMR8200)
❏
Servo horn drill (HCAR0698)
❏
Hobby Heat ™ micro torch (HCAR0750)
❏
Dead Center ™ Engine Mount Hole Locator (GPMR8130)
❏
AccuThrow ™ Deflection Gauge (GPMR2405)
❏
CG Machine ™ (GPMR2400)
❏
Precision Magnetic Prop Balancer ™ (TOPQ5700)
• When you see the term test fit in the instructions, it
means that you should first position the part on the
assembly without using any glue, then slightly modify or
custom fit the part as necessary for the best fit.
• Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When a
specific type of adhesive works best for that step, the
instructions will make a recommendation.
IMPORTANT BUILDING NOTES
Optional Supplies & Tools
Adhesives & Building Supplies
Hardware & Accessories
ADDITIONAL ITEMS REQUIRED
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
Tele: (800) 435-9262
Fax (765) 741-0057
Or via the Internet at:
http://www.modelaircraft.org
We, as the kit manufacturer, provide you with a top
quality, thoroughly tested kit and instructions, but
ultimately the quality and flyability of your finished model
depends on how you build it; therefore, we cannot in any
way guarantee the performance of your completed
model, and no representations are expressed or implied
as to the performance or safety of your completed model.
3
