11
Hook Up the Throttle
❏
1. Refer to following photos to see which of the two throttle
servo mounting locations will work best for your engine. Cut
the side or bottom servo mount hole from the location you
will use.
❏
2. Connect a 12" [305mm] servo extension to your throttle
servo and secure the connection with another piece of shrink
tubing.
❏
3. Mount the throttle servo and hook up the throttle using
the hardware shown in the photo. (It’s not necessary to
mount the muffl er yet, but it’s shown in the photo so you can
see how it fi ts and where to position the exhaust).
Install the Fuel Tank
❏
1. Prepare the stopper assembly as shown. Insert the
stopper into the tank and tighten the screw.
“Hook” side
11" [280mm]
“Loop” side
9" [230mm]
Overlap
5" [130mm]
Velcro Fuel Tank Strap
❏
2. Make the fuel tank strap from the included Velcro strip
as shown.
❏
3. Install the strap in the fuselage in the location you will
be mounting the tank—it may be necessary to temporarily
punch out one of the lightening holes to install the strap, then
glue the piece back in.
