4
Carefully lift the airplane from the cradle and set it aside, taking
care not to put excess pressure on the aileron control horns.
Remove the other components from the cradle. The transmitter
will lift easily out of its pocket if you slide it straight up by
pushing from the back.
LITHIUM BATTERY HANDLING & USAGE
ONLY use a LiPo approved charger. NEVER use a NiCd/NiMH
peak charger to charge a LiPo battery.
NEVER charge in excess of 4.20V per cell.
ONLY charge through the “charge” lead. NEVER charge
through the “discharge” lead.
NEVER charge at currents greater than 1C unless the battery
is rated for a higher charge rate.
ALWAYS set the charger’s output volts to match the battery
volts.
ALWAYS charge in a fi reproof location.
NEVER trickle charge.
NEVER allow the battery temperature to exceed 150 degrees
F (65 degrees C).
NEVER disassemble or modify the pack wiring in any way or
puncture the cells.
NEVER discharge below 2.5V per cell.
NEVER place the battery or charger on combustible materials
or leave it unattended during charge or discharge.
ALWAYS KEEP OUT OF THE REACH OF CHILDREN.
NEVER charge the battery in the plane.
ALWAYS remove the battery from the plane after a crash. Set
it aside in a safe location for at least 20 minutes. If the battery
is damaged in the crash it could catch fi re.
If the battery starts to swell, quickly move the battery to a safe
location, preferably outside. Place it in a bucket, covering the
battery with sand. Never use water to try and put out a LiPo fi re.
CHARGE THE BATTERY
The ElectriFly ® LiPo Battery Charger is great for simple balance
charging of 2-cell lithium-polymer batteries for small electric
models. Use it only to charge batteries within a capacity range
of 150 to 750mAh.
Specifications
Input voltage: 11.7 V –15V DC
Battery types, # cells: 2 lithium-polymer cells
connected in Series
( 7.4V LiPo)
Charge current: 450 mA maximum
Charge method: CC-CV (current drop-off
termination)
Battery capacity: 150 –750 mAh
Status indicator: Two LEDs;
one green, one red
Input connectors: polarized DC power jack
for DC input
Output connectors: one 2S balance plug
Case size: 2.18” x 1.13” x 3.26”
[55 x 28 x 82 mm]
Weight: 2.1 oz. [59 g]
Special Features
● A very economical, portable and simple way to
balance charge LiPo batteries
● Specifi cally designed for 2-cell 7.4V lithium-polymer
batteries only
