8
❏
10. Slide the wings together on the wing tube. Temporarily
mount the nylon strap to the wings with two #4 x 3/8" [9.5mm]
Phillips screws. Remove the screws from the strap, harden
the holes with a few drops of thin CA and allow it to harden
before putting the wings together and installing the screws.
Later, during fi nal radio and control throws set up, the pushrods
will be adjusted so the ailerons are centered when the radio
is on (or, you could reconnect your aileron servo to the radio
and do this now).
ASSEMBLE THE FUSELAGE
Install the Elevator and Rudder
❏
1. Cut the balsa block free from the stabilizer opening with
a hobby knife.
❏
2. Slide the horizontal stabilizer (stab) into the stab opening
in the back of the fuselage.
