Dash panel and steering wheel – Cub Cadet 5234D User Manual
Page 13
-13-
REF.
NO.
PART
NUMBER
CODE DESCRIPTION
QTY.
1
603-04305
Bracket, Throttle Cable ..................
1
2
629-04112
Wire Harness, Dash .......................
1
3
631-0076
Boot, Steering Shaft .......................
1
4
631-04007B
Dash ..............................................
1
5
703-05132A
Bracket, Throttle Mtg. ....................
1
6
710-0604A
Screw, Hex Wash. Hd. Tapp .........
5/16-18 x .625
2
7
710-0924
Screw, Pan Hd., 1/4-20 x .75 .........
4
8
710-3013
Screw, Hex Cap, 1/4-20 x .5 GR5
5
9
712-0116
Nut, Hex Insert Jam Lock, 3/8-24 ..
1
10
712-0237
Nut, Hex Lock, 5/16-24 ..................
1
11
712-0292
Nut, Speed, 1/4-20 .........................
2
12
723-3013
Washer, Friction, .515 x 1.5 x .12 ..
1
13
725-04022
Meter, Hour/Indicator .....................
1
14
725-04076
Switch, PTO ...................................
1
15
725-04241
Gauge, Fuel ...................................
1
16
725-04242
Gauge, RPM ..................................
1
17
725-2017
Plug ................................................
1
18
725-3274
Switch, Headlight ...........................
1
19
725-3277
Switch, Ignition ...............................
1
20
725-3279B
Switch, Hazard ...............................
1
21
731-05066
Panel, Meter ..................................
1
22
731-3209
Steering Wheel, Soft Grip ..............
1
23
731-3210
Cover, Steering Wheel ...................
1
24
731-3298
Handle, Throttle .............................
1
25
731-3344
Panel, Dash Insert .........................
1
26
731-3372
Extension, Dash .............................
1
27
736-0255
Washer, Belleville, .51 x 1.14 x .04
2
28
736-0329
Washer, Lock, 1/4 ..........................
2
29
736-04062
Washer, Flat, .344 x 1.5 x .1 ..........
1
30
736-0331
Washer, Belleville, .39 x 1.13 x .062
5
31
736-3072
Washer, Flat, .38 x .93 x .110 Hdn
1
32
732-04288
Spring, Torsion ..............................
1
33
738-04170
Screw, Shoulder, .374 x .56 ...........
1
34
759-3950
Key Set, Ingition .............................
1
35
725-04243
Lamp, Yellow Panel .......................
2
DASH PANEL AND STEERING WHEEL
