G X 8 5 0 I N S T R U C T I O N M A N UA L 3 3
SPECIFICATIONS
GENERAL RECEIVER
Frequency Range: 156.025 to 162.425 MHz Sensitivity (12dB SINAD): -119 dBm
Number of Channels: 56 International
52 USA
59 Canadian
10 Weather
Squelch: Threshold: -119 dBm
Tight: -113 dBm to -107 dBm
Hysteresis: 3~6 dB
Attack Time: <50 ms
Delay Time: <250 ms
Oscillator: PLL Rated Audio Output @5%
THD Speaker:
250 mW
Modulation: FM Adjacent Channel
Rejection:
> 70 dB
Channel Spacing: 25 kHz Image Rejection: > 70 dB
Frequency Stability: ±5 PPM Intermodulation
Rejection:
> 68 dB
Digital Selective Calling
(DSC):
Class D (EN301025) Spurious Response rejec-
tion (CH16) 80 MHz to
1 GHz:
> 70 dB
Man Over Board (MOB): DSC Channel 70 Conducted Spurious
Emission:
< 70 dB
Standard Operating
Temperature:
-20°C ~ +55°C Scan Time per Channel: 200 ms
Nominal Working Volt-
age:
7.4 V DC RX Current: Standby – 185 mA
Max Audio Power – 380 mA
Low Voltage Limit: 6.8 V DC TRANSMITTER
Battery Life (5% TX, 5%
RX, 90% Stby):
≥8 Hrs Output Power: High – 5W
Low – 0.8W
Antenna Socket : SMA Frequency Tolerance: ±2.5 PPM
Built in Speaker: 40 mm Diameter, 8 Ohms Max Modulation: ± 5 kHz
Dimensions: 67 (W) x 153 (H) x 43 (D)
mm
Conducted Spurious
Emission:
< -56 dB
Battery: 7.4 V 1700 mAh Li-Polymer Audio Distortion @ 3 kHz
Dev:
< 5%
DC Charger: 9 V @ 1000 mA Conducted Spurious
Emission:
< -56 dB
Charging Current: 760 mA ± 130 mA TX Current: High Power – 1.6 A
Low Power – 0.9 A
GPS Receiver: 48 Channel Specifications are nominal and are subject to change
without notice or obligation
Waterproof: IP67
