Mk00 1b ins tall a tion - cuttin g templ a te – GME GR200WEP1 User Manual
Page 18
MK00
1B INS
TALL
A
TION - CUTTIN
G TEMPL
A
TE
66 mm
8 mm
2.5 mm
165 mm
10 mm Drill Bit
Mounting
Screw Clearance
8 mm Drill Bit
Mark and cut a hole 66 mm (h) by 165 mm (w),
allowing for clearance of the two mounting screws holding the radio to the surround.
Use a 10 mm drill bit to form the radius of the corners and an 8 mm drill bit
for the clearance of the mounting screws
.
