Hold the mounting bracket in place
(with the EPIRB removed) and mark the
location of the mounting holes. Screw the
bracket to the panel or bulkhead using
the stainless steel screws supplied.
NOTE:
The locations of the mounting
holes for the mounting bracket are
identical to those used on the earlier
MT400 series EPIRBs.
Once the bracket is fixed in place, fit the
emergency beacon to the bracket.
BRACKET RELEASE AND STOWAGE
To remove the EPIRB
1. Release metal strap by pulling clasp forward.
2. With one hand, press down on the tab at the base of the bracket.
3. Grasp the EPIRB with the other hand and pull it outwards and downwards.
4. The antenna will release automatically and spring to the upright position.
Mounting
holes
Mounting
holes
