Black plate (33,1) GMC Acadia/Acadia Denali Owner Manual - 2012
Vehicle Care 10-33
Fuses Usage
TRLR
BCK/UP
Trailer Back‐up
Lamps
TRLR BRK Trailer Brake
TRLR
PRK LAMP
Trailer Parking
Lamps
TRLR PWR Trailer Power
WPR/WSW
Windshield Wiper/
Washer
Relays Usage
A/C
CMPRSR
CLTCH
Air Conditioning
Compressor Clutch
AUX
VAC PUMP
Auxiliary
Vacuum Pump
CRNK Switched Power
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
FAN 3 Cooling Fan 3
FOG LAMP Fog Lamps
Relays Usage
HI BEAM
High‐Beam
Headlamps
HID/
LO BEAM
High Intensity
Discharge (HID)
Low‐Beam
Headlamps
HORN Horn
IGN Ignition Main
LT TRLR
STOP/TRN
Trailer Left
Stoplamp and Turn
Signal Lamp
PRK LAMP Parking Lamp
PWR/TRN Powertrain
RR DEFOG
Rear Window
Defogger
RT TRLR
STOP/TRN
Trailer Right
Stoplamp and Turn
Signal Lamp
Stop Lamps
(China Only)
Stop Lamps
(China Only)
Relays Usage
TRLR
BCK/UP
Trailer Back-up
Lamps
WPR Windshield Wiper
WPR HI
Windshield Wiper
High Speed
Instrument Panel Fuse
Block
The instrument panel fuse block is
located under the instrument panel
on the passenger side of the
vehicle. Pull down on the cover
to access the fuse block.
