Appendix
ST-3000LED User Manual 15 2009-12-10 / 14:04
DMX C
HANNEL
V
ALUES
NOTE!
Please read all instructions carefully on fixture DMX control mode and addressing.
DMX channels 2, and 3 functions are determined by the current settings of channel 1. For example,
while Channel 1 is set between 000 and 029 the following conditions will apply;
 Channel 2 will control Strobing from 0% to 100%
 Channel 3 will control Dimming Intensity from 100% to 0%
Channel Value Function Ch 2 Ch 3
1
000  039 Dimmer /Strobe
Mode
Strobe
0  255
Intensity
100% 0%
040  079 Program 1
Speed
Slow  Fast
080  119 Program 2
120  159 Program 3
160  199 Program 4
200  239 Program 5
240  255 Sound No Function
