•CONTENTS AND RATINGS
Ratings and specifications are subject to change without prior notice.
Model
Transmitter
Receiver
Servos
Switch
Nicd battery
Accessories
FP-8SGAP
FP-T8SGAP x 1 with module FP-TF-FM
FP-R118GPx 1
FP-S130x4
SWH-5x 1 (R4-SWJx 1)
NR-4J x 1
Battery charger, landing gear adaptor, DSC cord, CHG adaptor, DSC-CHG
cord, servo tray, frequency flag, spare horn, neck strap, screws
Transmitter FP-T8SGAP Receiver FP-R118GP
Operating system
Transmitting
frequency
Modulation
Power requirement
Current drain
Chosen
band
: Two-stick, 8 channels for
F3A pattern
: 50/53MHz BANDS
72/75MHz BANDS
53MHz <-> 72MHz
Frequency change to any of
above bands is possible by
merely changing RF module.
: PCM, FM
: 9.6V 8/500mAH internal
Nicd battery
: 250mA
Receiving frequency
Intermediate
frequency
Power requirement
Current drain
Dimensions
Weight
Receiving range
50/53MHz BANDS
72/75MHz BANDS
455kHz
Chosen
band
4.8V Nicd battery (shared
with servo)
42mA (4.8V reception)
2.23 x 1 . 6 5 x 0 . 9 4 in
(57 x 52 x 24mm)
1.85oz (53g)
500m on the ground
1000m in the air
When FP-T8SGAP used.
(At the best radio wave con-
dition of environment)
Servo FP-S130 Landing Gear Servo FP-S130G (Option)
Control system
Operating angle
Power requirement
Current drain
Output torque
Operating speed
Dimensions
Weight
+pulse width control, 1520
uS.N
One side 45° or greater (in-
cluding trim)
4.8V (shared with receiver)
5mA (at idle)
55.6oz.in (4kg-cm)
0.24 sec/60°
1.52x0.77 x 1.36 in
(38.5 x 19.5x34.5mm)
1.47oz (42g)
Control system
Operating angle
Power requirement
Current drain
Output torque
Operating speed
Dimensions
Weight
+pulse width control
Rotary approx 160°
4.8V (shared with receiver)
8mA (at idle)
65.3oz.in (4.7kg-cm)
0.34 sec/60°
1.52 x 0.77 x 1.36 in
(38.5 x 19.5 x 34.5mm)
1.48oz (42g)
Battery Charger FBC-8B(2) Receiver Servo Nicd Battery NR-4J
Input voltage
Output
: 120 VAC, 50/60 Hz
: TX side
9.6V/45mA
RX side 4.8V/45mA
Voltage
Dimensions
Weight
: 4.8V, 4/500mAH
: 2.01 x 2.28 x 0.59 in
(51 x 58 x 15mm)
: 3.35oz (95g)
