Fredenstein Bento 10D Module Carrier

Pin 11

AUX In +

Pin 12

+16V Supply

Pin 13

Supply Ground

Pin 14

-16V Supply

Pin 15

+48V Supply

Component Side

Pin 1

Frame Ground

Pin 2

Main Out +

Pin 3

Digital Interconnect 1

Pin 4

Main Out -

Pin 5

Audio Ground

Pin 6

Compressor Buss

Pin 7

Digital Interconnect 2

Pin 8

Main In -

Pin 9

Digital Interconnect 3

Pin 10

Main In +
