4 106197
DECORATIVE PATIO FIRE
PROPANE/LP GAS
CONNECTING TO GAS
SUPPLY
CAUTION: Never connect ap-
pliance directly to the propane/LP
supply. This appliance requires a
two stage external regulator (not
supplied). Install the external regu-
lator between the appliance and
the propane/LP supply.
WARNING: Only a qualified
service person must install gas
piping and connect appliance to
gas supply. Follow all local codes.
INSTALLATION
NOTICE: Installation, service, and
repair of this appliance must be
performed by a qualified installer,
service agency, company, or gas
supplier experienced with this type
of gas appliance. Only factory au-
thorized components listed in these
instructions may be used in accor-
dance with the manufacturer’s in-
structions and all codes and re-
quirements of the authority having
jurisdiction. Any modifications to
this appliance, or use of unautho-
rized components or accessory
items will void the manufacturer’s
warranty, and may result in a haz-
ardous condition.
CHECK GAS TYPE
Use only propane/LP gas. If your gas supply is
not propane/LP gas, do not install appliance.
Call dealer where you bought appliance.
WARNING: Do not remove
the metal data plates attached
to this appliance. The data plates
contain important warnings and
instructions.
DECORATIVE GAS PATIO FIRE
SPECIFICATIONS
PROPANE/LP GAS:
RATED PRESSURE*
11.0" W.C.
MINIMUM GAS
PRESSURE*
10.0" W.C
MAXIMUM GAS
PRESSURE*
14.5" W.C.
INTERNAL REG.
SET POINT
8.0" W.C.
ORIFICE DRILL
SIZE
30 (.128")
BTU/HR
OUTPUT
70,000
SHIPPING WEIGHT 190 LBS.
Figure 2 - Technical Information Chart
LOCATING APPLIANCE
When locating this appliance, follow all
safety information on pages 2 and 3.
Do not use this appliance indoors. It is for
outdoor use only. Do not locate this product
in even a partially enclosed area, such as a
garage or underneath a patio cover or ga-
zebo. They could be damaged or set on fire.
Locate this appliance on a level, outdoor,
noncombustible surface. Do not place this
appliance on grass or dirt. This may prevent
proper safety venting. Do not operate where
wind or excessive drafts are present.
Maintain proper clearance from combus-
tible materials.
• Never place this appliance directly on
any combustible surface.
• Make sure combustible materials are at
least 20 feet above appliance. This in-
cludes tree limbs.
• Make sure combustible materials are at
least 4 feet from sides of appliance.
Make sure to locate appliance where gas
hose is out of traffic areas. This will help
prevent people from tripping over the hose.
This will also help prevent accidental dam-
age to the hose.
UNPACKING
WARNING: Do not remove
the metal data plates attached
to this appliance. The data plates
contain important warnings and
instructions.
1. Remove lava rock and log pack from
carton.
2. Carefully lift firepit out of carton and
gently place at site of installation.
3. Check all items for any shipping dam-
age. If damaged, promptly inform
dealer where you bought the product.
Note: Deterioration or damage due to se-
vere weather conditions such as hail, hurri-
canes, earthquakes, or tornadoes, or discol-
oration due to exposure to chemicals either
directly or in the atmosphere, is not covered
by the Limited Warranty on the back of this
manual. The warranty also does not cover
the following:
• weather damage caused by not using the
protective cover
• chips, cracks, or breakage caused from
dropping, dragging, or hitting firepit.
The surface of the firepit naturally contains
spaces, surface cracks, and variations in color
and texture. The limited warranty does not
cover such surface imperfections.
HIGH ALTITUDE DERATE
In the U.S.A., input BTU shall be
derated 4% (1 orifice size) per 1,000
feet for altitudes above 2,000 feet. In
Canada, input BTU shall be derated
10% (2 orifice sizes) at altitudes from
2,000 to 4,500 feet.
*Measured at entry of flexible supply hose.
