13

106197

OWNER’S MANUAL

PARTS LIST

This list contains replaceable parts used in your appliance. When ordering parts, follow the
instructions listed under Replacement Parts on page 10 of this manual.

PATIO FIRE
PC3460LP

KEY NO.

PART NO.

DESCRIPTION

QTY.

1

106116-02

Burner Assembly

1

2

106117-01

Burner Plate

1

3

106118-01

Burner Plate Bracket

4

4

106051-01

Injector, LP

1

5

106193-01

Outlet Tube Assembly

1

6

102367-01

Gas Valve

1

7

098508-01

Nut, Valve Retention

2

8

098276-01

Valve, Cap

1

9

099393-03

Valve Knob

1

10

106137-01

Thermocouple

1

11

106122-01

T-C Bracket, LP

1

12

106711-01

T-C Cover

1

13

106120-01

Front Mounting Plate

1

14

106121-01

Control Bracket

1

15

106130-01

Spark Module

1

16

106715-01

Grounding Wire Assembly

1

17

106134-01

Electrode Assembly

1

18

106123-01

Firepit

1

19

M10908-14

Screws, Sheet Metal

18

20

M11084-38

Screw, #8 x .38

2

21

101628-01

Inlet Tube

1

22

106712-01

Supply Hose

1

23

098867-03

Pressure Regulator

1

24

097809-02

Reg. Inlet Fitting

1

25

097809-02

Reg. Outlet Fitting

1

26

106718-01

Hose Clamp

1

PARTS AVAILABLE — NOT SHOWN

106204-01

Lava Rock

1

106046-01

Logs (Set of 6)

1

106717-01

Protective Cover

1

106749-01

Lighting Instructions Plate

1

106750-01

Warning & Rating Plate

1
