Instruction and Operation Manual
for ATEX Approved Load Cells
Last revision: 24.10.2014 Revision: 9.5 Page 6 / 12 Date of 1st issue: 03.06.2002
4. Commissioning and Installation
a) This equipment (load cells) can be used either in zone 0, 1 or 2, or zone 20, 21 or 22 in explosion
groups IIA, IIB, IIC, IIIA, IIIB, or IIIC.
b) The allowed ambient temperature range is –40°C to 45°C/60°C.
c) This equipment complies to protection class > IP67 / EN 60529.
d) This equipment must be electro statically grounded.
e) The load cell must not be used if it is defective or shows any visible damage.
f) Load cells must not be re-used in an intrinsically-safe circuit if they have already been operated in a
circuit in zone 2 or 22,
5. Usage
WARNING : Misuse will cause the loss of warranty and manufacturer’s responsibility.
The load cells are only allowed for professional applications in accordance with the load cell data sheet and
Flintec application parts.
a) If the load cells are not, powered from an intrinsically-safe circuit the connection cables must either be
lead out of the hazardous area to terminate them or terminated in suitable junction boxes.
b) If used in hazardous dust environment, the dust layer on the load cell body must not exceed
5 mm in thickness.
c) The load cell types PC22, PC42, PC46, PC60 and ZLB have an aluminium housing. If used in zone 0,
the general precautions for the application of light metals must be followed .
For example , Protection against impact energy.
d) The load cells type BK2, PC1, PC22, PC42, PC46, PC60, SB5, SLB, UB5, ULB and ZLB have a plastic
surface > 4 cm
2
. If used in zone 0 precautions against electrostatic charging must be implemented.
e) In zone 0 and in the apparatus group IIC the connecting cables of the load cells must be laid
protectedly against static charges
6. Maintenance
Maintenance interventions on the load cells have to be carried out by Flintec personnel only.
7. Repair
This equipment is certified for use in hazardous locations, therefore no modifications are allowed. Repairs
must only be performed by personnel specifically trained for repairs of this equipment.
8. Waste Disposal
The waste disposal of package and shipped parts must be done in accordance with the regulations of the
country in which the equipment is installed.
