Quickspecs – Compaq 2510p User Manual

Page 16

HP 65W Smart AC

HP 65W Smart AC
Adapter

Adapter

Dimensions

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

Weight

0.62 lb (280 g)

Input

100 to 240 VAC

Input Efficiency

83% min at 115 VAC

Input frequency range

47 to 63 Hz

Input AC current

1.7 A at 90 VAC, 0.85 A at 180 VAC

Output

Output power 65W

65W

DC output

18.5V

Hold-up time

5 msec at 115 VAC input

Output current limit

<11A, Over voltage protection- 29V max
automatic shutdown

Connector

3 pin/grounded, mates with interchangeable cords

Environmental Design

Operating temperature

32° to 104° F (0° to 40° C)

Non-operating (storage)
temperature

–4° to 149° F (–20° to 65° C)

Altitude

0 to 10,000 ft (0 to 3,048 m)

Humidity

20% to 80%

Storage Humidity

10% to 90%

EMI and Safety

EMI and Safety
Certifications

Certifications

CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B,
CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at
25°C ambient condition.

9-Cell (83WHr) Lithium-

9-Cell (83WHr) Lithium-
Ion battery

Ion battery

Dimensions

Dimensions (H x W x L)

1.6 x 2.3 x 8.1 in (4.1 x 5.9 x 20.6 cm)

Weight

1.07 lb (0.488 kg)

Cells/Type

9-cell Lithium-Ion

Energy

Watt-hour Capacity

83Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F (–10° to 60° C)

Non-operating

–4° to 140° F (–20° to 60° C)

Battery Re-Charge Time

System in OFF mode or
Standby

3 to 4 hours

System ON

4 to 5 hours (depending on system power
consumption)

Fuel Gauge

When pressed, LEDs light indicating level of charge remaining on battery

QuickSpecs

HP Compaq 2510p Notebook PC

Technical Specifications

DA - 12717 Worldwide — Version 10 — August 10, 2007

Page 16
