FZR 2020-E

Machine description and items delivered

3. MACHINE DESCRIPTION AND ITEMS

DELIVERED

Machine Description (See fig. 1)

Switch lever
Upper handle
Switch box
Safety switch
Plug (connector)
Grass catcher box
Engine cover
Extension cord retainer
Bolt and nut for handle attachment
Lawnmower chassis
Wheel

1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -

10 -

11 -

Items Delivered

Remove the machine carefully from the packaging and check the completeness of the following
parts:

2x lower part of the handle

1x upper part of the handle

2x bolt for attaching the lower part of the handle

2x nut and bolt for joining the lower and upper part of the handle

1x supply cable holder

1x grass catcher box

4x wheel

4x split pin and washer for mounting the wheel

4x wheel cover
