FZV 2001-E
14 EN Machine assembly | Switching-on
Pull out the lever (1) and move it forward or backward for both wheels according to the
required swath depth. We recommend adjusting the position on the same level for both
wheels.
Swath depth setup:
Loosening Verticutting
Position 1 (from rear end) 10 mm 4 mm
Position 2 6.5 mm 0.5 mm
Position 3 3.0 mm -3.0 mm
Position 4 -0.5 mm -6.5 mm
Position 5 -4.0 mm -10 mm
Connection to the electrical network (Fig. 3)
Connect the connecting cable of the equipment to the safety combined switch / connector
and secure with the aid of the clamp. The power supply cable loop shall be sufficiently long in
order to move the clamp from one side of the handle to the other side.
6. SWITCHING-ON
Main switch On/Off (Fig. 4)
Warning! Do not start-up the verticutter while being in high grass or on the solid ground.
Push the button A of the safety combined switch / connector and then draw the switch
lever B towards the handle.
Hold the switch lever drawn while releasing the press on the safety switch button.
You can stop the equipment by releasing the switch lever and it will return back to its home
position automatically.
Protection against overheating
If the equipment was blocked by a foreign object or the engine was overloaded, the protective
circuit is activated and the engine gets switched-off automatically. Wait until the engine cools
down (about 15 minutes) and then start-up the equipment again.
Warning! If you did not release the switch lever, the equipment starts-up automatically after
cooling down. Risk of accident!
