10 EN Explanation for instruction plates on the machine | Machine description and delivery content
3. MACHINE DESCRIPTION
AND DELIVERY CONTENT
Machine description (see Fig.1)
Safety combined switch (On / Off) with a
connector
Guiding handle
Safety cover
Exhauster
Lawn verticutter N1B-JY-30
Scarifying roll 1 -
2 -
3 -
4 -
5 -
6 - 7 - Raking roll (optional)
8 - Collection box (optional)
Before carrying out setup or
maintenance of the machine, or if the
power supply cable got caught or was
damaged, always switch-off the engine
and pull the plug out of the power
socket first!
Use protective equipment while
working.
Before carrying out any work on the
mowing equipment, pull the cable out
of the power socket first!
