3. MACHINE DESCRIPTION AND
DELIVERY CONTENT
Machine description (see Fig.1)
Use of the product
The brush cutter is only intended for cutting of grass, weed, bush or underbrush. It must not be
used for other purposes, e.g. trimming of lawns or hedges because an injury may occur in this
case.
Machine characteristic
Electronic ignition system
Automatic centrifugal clutch
Spiral transmission
Cardan shaft
WARNING! Sharp blades.
Delivery content
Take the machine carefully out of the package and check whether there are all following
components:
Garden brush cutter
Cord head with a cord of 2.5m length and 2.4mm diameter
Disc head
3-teeth blade
Tubular spanner
Operation manual
In the case of some parts missing or damaged, please, contact the dealer where you’ve bought
the machine.
Motor
Air cleaner
Suspension
Main switch + gas activator
Handle bar grip holder
Handle bar
Shaft 1 -
2 -
3 -
4 -
5 -
6 -
7 - 8 -
9 -
10 -
Housing
Gearbox body
Cutting tool
