Clarion VRX585USB - Manual (Page 38)

40
English
Owner’s manual
39
English
Owner’s manual
7-3 RADIO
(1) Listening to the radio
Press the [SOURCE] button and touch the [TUNER] key. The TUNER mode screen is
displayed.
Press the [BAND] button on the remote control unit, or touch the [BAND] key to select the radio
band. Each time the key is touched, the radio reception band changes in the following order:
FM1 FM2 FM3 AM1 AM2 FM1 …
The default setting is “FM1”.
Touch the [ ] or [ ] key to seek up or seek down.
If you keep touching the [ ] key, manual tuning will be done in the direction of lower frequencies.
If you keep touching the [ ] key, manual tuning will be done in the direction of higher frequencies.
AREA BAND
RECEIVING STEP STEP
IF(Hz)
BAND(Hz) SEEK(KHz) MANU(KHz)
U.S.A
FM1,2,3 87.9~107.9M 200 200 10.7M
AM1,2 530~1710 K 10 10 450K
FREQUENCY MAP
(2) Auto store
The Auto Store is a function for storing up to 6 stations that are automatically tuned in
sequentially. If 6 receivable stations cannot be received, a previously stored station remains at
the memory position.
Touch and hold the [AS] key more than 2 seconds. A beep sounds and the stations with good
reception are stored automatically to the preset channels.
(3) Specification of conversion
When the 2ZONE function turns on, the source of the main-zone and the sub-zone is made up
by the mixture besides of the external source.
The source conversion of the main-zone is available when the 2ZONE setting mode sets up to
the main-zone.
The source conversion of the sub-zone is available when the 2ZONE setting mode sets up to the
main-zone.
The source conversion of the main-zone and sub-zone is like below.
3 DVD VISUAL(AUX) 2 iPod (Video) RADIO USB
RADIO 1 Y 1 Y 1 Y N N
DVD Y Y Y N N
VISUAL(AUX) Y Y N N N
iPod Y Y Y N N
USB Y Y Y N N
MAIN
SUB
NOTE
1 : Receiving condition of some stations may be altered in 2ZONE mode.
2 : To select the video mode of iPod when you watch in sub-zone.
3 : DVD operation can be done only in the main-zone.
