34
English
Owner’s manual
33
English
Owner’s manual
7-2-5 ADJUST Operations
ADJUST
CAMERA INT.
CAMERA WARNING
NTSC/PAL/AUTO
CLOCK
BEEP
AUTO PANEL
TEL SWITCH
TEL SPEAKER
ADJ
GENERAL
MONITOR
BRIGHT
COLOR
HUE
DIMMER
item table
(1) Adjusting the MONITOR : At Tuner, iPod, USB Mode
(1-1) Default Screen
Press the [ADJ] button.
Perform the adjustment.
Touch the [BACK] key to return to the previous screen.
(1-2) MONITOR ADJUST
(1-2-1) Brightness
Touch the [ADJUST] key to adjust brightness for display image.
Touch the [ - ] key and screen becomes dark
Touch the [ +] key and screen becomes bright
(1-2-2) Dimmer
Touch the [ADJSUT] key to adjust the brightness of LCP when the car lights are on/off.
[DAY] : Brightness of LCP is always set to maximum level.
[NIGHT] : Brightness of LCP is always set to user setting level in adjust mode.
OTHERS DEFAULT SETTING RANGE
SUB WOOFER VOL 0 -6 ~ +6
M-B EX OFF ON or OFF
HIGH PASS FILTER THROUGH 120Hz or THROUGH
LOW PASS FILTER 50Hz 50Hz or 80Hz or 120Hz or THROUGH
AMP CANCEL OFF ON or OFF
(3) Adjusting the OTHERS
Touch the [OTHERS] key
Touch the value at right side to adjust the desirable function.
“SUB WOOFER VOL” controls the volume level of the subwoofer.
“M-BX ON” boosts low sound of below 50Hz.
“HPF” controls the Output of POWER-AMP.
“LPF” controls the Output of SUB-WOOFER.
“AMP CANCEL” controls the using presence of built-in AMP.
If you use the external AMP, Built-in AMP is recommended to be turned off.
(2) Adjusting the BAL/FAD
Touch the [BAL/FAD] key.
Touch the [FRONT] [LEFT] [RIGHT] [REAR] keys to control balance & fader.
They control a location adjustment of the sound. Their default settings are “CENTER”.
KEY RANGE FUNCTION
FADER
[FRONT] 0 ~ 12 Emphasize front speaker sound
[REAR] 0 ~ 12 Emphasize rear speaker sound
BALANCE
[LEFT] 0 ~ 13 Emphasize left speaker sound
[RIGHT] 0 ~ 13 Emphasize right speaker sound
ITEM SETUP
