Curtis TC972 - Manual (Page 7)

Base Unit Controls
6
Page
Power In Use/Chg
4. Base Unit Antenna
1. Tone/Pulse Select Switch
1. Tone/Pulse Select Switch
2. Power-In Connection Jack
3. Telephone Line Connection Jack
6. Charge Terminals
8. In Use/Charge LED Indicator
7. Power LED Indicator
5. Page button
4. Base Unit Antenna
2. Power-In Connection Jack
3. Telephone Line Connection Jack
6. Charge Terminals - For charging the Handset battery pack. For best performance, clean
the Charge terminals periodically with a damp cloth.
8. In Use/Charge LED Indicator - (IN USE) Lights up to indicate that the Handset is in TALK
mode. (CHARGE) Lights up when the Handset is placed on the Base Unit for charging.
7. Power LED Indicator - Lights up when power I connected to the Base Unit.
5. Page button - Press to page the Handset
12VDC
200mA
TONE /P ULSE TEL LINE
