Empress Effects Tremolo2 - Manual (Page 9)

Controls at a Glance
Power: 9V - 12V DC. 100mA or greater
Presets: When scrolling through presets, this LED will flash.
Press the bypass switch to engage the new preset.
Triangle: Your standard tremolo waveform. Smooth ramp
from loud to soft.
Tube: An asymetrical waveform modeled after classic tube
amp tremolo.
Square: Tremolo turns on and off with no volume ramp.
Great for choppy sounding effects.
Waveform: Sets the shape of the tremolo envelope.
Bypass: Press to engage / bypass the pedal. When the LED is
illuminated, the tremolo is engaged.
Rhythm: Here are the eight rhythms with "0" being
accented:
1) 0000 (normal tremolo)
2) 0x0x
3) 0xx0xx
4) 0xxx0xxx
5) 0xx0xx0x
6) 0x0x00x0x0 (this one is in 5/4)
7) 0xx0xx0x0x0x
8) 0xx0xx0xxx0x0xxx
Output: Sets the overall output level (volume) of the pedal.
Control Port: Control the tremolo via expression
pedal, external tap, control voltage and MIDI.
Input
Save: Use to save presets and assign expression pedal control.
