S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
117
C o o p e r L i g h t i n g
O V H F L AT G L A S S
R O A D W AY
P H O T O M E T R I C S
[ C o m p l e t e I E S f i l e s a v a i l a b l e a t w w w. c o o p e r l i g h t i n g . c o m ]
O V H 1 5 S 2 D . I E S
150-Watt HPS
16,000-Lumen Clear Lamp
Type II-Medium Cutoff
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
E
A
B
C
D
O V H 1 5 S 3 D . I E S
150-Watt HPS
16,000-Lumen Clear Lamp
Type III-Medium Cutoff
D
E
C
B
A
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
F O O T C A N D L E TA B L E
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting
Footcandle Values for
Height
Isofootcandle Lines
A
B
C
D
E
OVH15S2D.IES
20'
3.12
1.56
0.78
0.39
0.16
25'
2.00
1.00
0.50
0.25
0.10
30'
1.30
0.65
0.33
0.16
0.07
35'
1.02
0.51
0.26
0.13
0.05
OVH15S3D.IES
20'
3.12
1.56
0.78
0.39
0.16
25'
2.00
1.00
0.50
0.25
0.10
30'
1.30
0.65
0.33
0.16
0.07
35'
1.02
0.51
0.26
0.13
0.05
Light
Lens
Wattage
Source
1
Type
II MCO
III MCO
50-150
HPS
Flat Glass
OVH15S2D
OVH15S3D
(150W)
(150W)
175
MH
Flat Glass
OVH17M2D
OVH17M3D
(175W)
(175W)
200-250
HPS
Flat Glass
N/A
OVH25S3D
(250W)
NOTE: 1 All light sources are clear unless noted otherwise.
P H O T O M E T R I C D I S T R I B U T I O N
[ C u r v e N u m b e r ]
