Equipment Instruction Manual
EDCO Model TILE SHARK
HOW TO ORDER REPAIR PARTS
To insure product safety and reliability, always use genu-
ine EDCO replacement parts when making repairs to the
equipment.
When ordering parts, please specify the MODEL and
SERIAL NUMBER of the machine as given on the NAME-
PLATE. In addition, give part number, description and
quantity as listed on the parts list.
Please note: Due to improvements and changes in the
equipment the illustrations shown may be different from
the actual machine.
Toll Free: Voice 1-800-638-3326 • Fax 1-800-447-3326
Figure 1
Table of Contents
Section Page Number
Safety Guidelines ............................................................................................................4
Operating Instructions ....................................................................................................5-6
Changing the Blade .........................................................................................................6
Maintenance ....................................................................................................................7
Limited Equipment Warranty .....................................................................................Back Page
< >
<
41”
104.1 cm
<
< >
24 1/2”
62.2 cm
<
40 1/2”
102.9
cm
Specifications & dimensions are for
reference only and subject to change.
Length
Width
Height
Total Weight
40 1/2”
24 1/2”
41”
102.9 cm
62.2 cm
104.1 cm
145 lbs. 65.8 kg
>
Handle bar locking tab
bottom side of handle bar.
NOTE: Due to improvements your machine may not appear the same as the pictures in this manual.
8 1/4”
21 cm
Shown in folded
upright position
Slide bar up towards
handle bar to release
fold handle forward.
Handle bar locking
tab slot.
