Figure 2
Figure 1
Guide to Operation
Connect air supply hose to connector on machine.
Connect “WHIPCHEK” on machine to air supply hose.
Position yourself behind machine and turn operating lever
to operating position and proceed to operate machine.
Connect industrial vacuum to vacuum port on machine.
Figure 3
View of underside of machine.
Dust skirt
Bits
Vacuum port
