TUNGSTEN CARBIDE BITS
5 - POINT
Item no. 18810
General surface removal
Penetration up to 1/4 inch.
9 - POINT
Item no. 18820
Laitance removal
Fine scabbling
Anti-slip surfacing
Penetration to 1/8 inch.
Use 5-Point bits for general purpose
removal of concrete due to spalling,
blistering, excess surface material, or in
preparation of bonding new concrete
overlays. Depth of removal is generally
1/4” or more and is dependent on the
speed with which the unit is moved
across the surface.
The 9-Point bits achieve surface
removal of approximately 1/8”. Creating
an excellent bonding texture for overlays
of thin coats of polymer concrete, epoxy
or urethane. Also ideal for producing
slip-resistant surfaces for fork trucks
and other vehicular traffi c.
Bits are easily and quickly changed or replaced. The uses listed above are merely suggested.
Your own trials will determine which bit fi ts your need best. Choose the correct type to do the job.
Use a hammer and punch to drive out the bit retaining pins. Remove the bits, replace and drive
the retaining pins back in securely. If pins are loose or worn replace with new tight fi tting pins.
***WARNING***
***WARNING***
“DO IT RIGHT” OR RISK SEVERE PERSONAL INJURY.
FOLLOW INSTRUCTIONS CAREFULLY
