Operating instructions – ebm-papst S2E300-AP02-50 User Manual
Page 8
Operating instructions
S2E300-AP02-50
Translation of the original operating instructions
4.4 Connection screen
L
= U1 = blue
Z
brown
N
= U2 = black
PE
green/yellow
