Christie LX25a
Specifications
Performance specifications are typical. Due to
constant research, specifications are subject to
change without notice.
Auto set-up gives you perfect image and
automatic vertical keystone correction. The short-throw zoom lens produces large images when space is limited.
Corporate Offices
USA
10550 Camden Drive
Cypress, CA 90630
PH: 714-236-8610
FX: 714-503-3385
Toll free: 866-880-4462 (NA only)
[email protected]
CANADA
809 Wellington Street North
Kitchener, Ontario N2G 4Y7
PH: 519-744-8005
FX: 519-749-3136
Toll free: 800-265-2171 (NA only)
[email protected]
Worldwide Offices
UNITED KINGDOM
PH: +44 118 977 8000
FX: +44 118 977 8100
[email protected]
GERMANY
PH: +49 2161 664540
FX: +49 2161 664546
[email protected]
FRANCE
PH: +33 (0) 1 47 48 28 07
FX: +33 (0) 1 47 48 26 06
Mobile: +33 (0) 6 76 47 43 62
[email protected]
SINGAPORE
PH: +65 6877 8737
FX: +65 6877 8747
[email protected]
SHANGHAI
PH: +86 21 6278 7708
FX: +86 21 6270 5816
[email protected]
BEIJING
PH: +86 10 6561 0240
FX: +86 10 6561 0546
[email protected]
JAPAN
PH: +81 3 3559 7481
FX: +81 3 3599 7482
[email protected]
• 2500 ANSI lumens
• 85% brightness uniformity
• Contrast ratio: 450:1 on/off
DISPLAY TECHNOLOGY
AND RESOLUTION
• 3 x 0.8" p-Si Active Matrix TFT LCD
panels with Micro Lens Array
• True XGA (1024 x 768)
• 8-bit color resolution offering 16.7 million
displayable colors
INPUT SIGNAL
COMPATIBILITY
• VGA to SXGA
• STV, DTV and HDTV
• Digital Visual Interface (DVI-I)
HDCP compliant
• Progressive scan video decoding with
automatic 3-2 pulldown
SCAN RATES
• Horizontal – 15 kHz to 100 kHz
• Vertical – 50 Hz to 100 Hz
PIXEL CLOCK
• 140 MHz
STANDARD LENS
• Manual zoom: 1.25 – 1.95:1
• Screen size: 40"– 300"
• Manual zoom and focus
INPUTS, CONTROL AND
NETWORKING
• DVI-I (24-pin digital RGB); audio input
(stereo mini-jack)
• HD15 (analog RGB, YPbPr); audio input
(stereo mini-jack)
• Composite (RCA); S-Video (4-pin
mini-DIN); audio input (2 x RCA L/R)
• Control port input: 8-pin mini DIN and
USB Type B
• Automatic set-up (phase/tracking/
positioning/keystone correction)
• Optional ChristieNET™ for connection
to TCP/IP network
• IR remote keypad with laser pointer and
mouse control
OUTPUTS
• HD15 (analog RGB)
• Audio (stereo mini-jack)
• Single 1W speaker
ENHANCED FEATURE SET
• PIN code security for power on
• “Blackboard” mode to optimize
display on green chalk boards
• Color management system (built-in)
• Horizontal and vertical digital keystone
correction, +/- 40˚ vertical, +/- 20˚
horizontal
• Dual mode input/output HD15 connector
for loop through or monitor connection
• Digital zoom and pan (max. x49)
• User-definable start-up screen
• Software lock for keypad or remote
• Front/rear/ceiling mount orientations
GRAPHICAL USER INTERFACE
• Easy set-up, on-screen display (OSD)
• Image aspect ratios: standard 4:3
or wide 16:9
• Menus in eleven languages
LAMP
• 200W lamp
• Lamp life of 1500 hours (typical)
POWER REQUIREMENTS
• 100 VAC to 240 VAC +/- 10% @ 50/60 Hz
• Power consumption: 300W maximum
• Thermal dissipation: 1025 BTU/hr
• Operating temperature: 40 to 95˚ F (5 to
35˚ C) [storage 14 to 140˚ F (-10 to 60˚ C)]
• Acoustic noise level: 34dBA
DIMENSIONS
• Weight: 6.2 lb (2.9 kg)
• Size: 11.7" W x 2.8" H x 8.4" L
(298mm W x 71mm H x 214mm L)
STANDARD ACCESSORIES
• User manual
• HD15-DVI-I computer cable
• Mouse control cable (USB)
• Soft-sided carrying case
• AC cord x 2 (UL and European line cord)
OPTIONAL ACCESSORIES
• ChristieNET™ networking
• Lamp module
• Component to HD15 video cable
• Ceiling mount
• Shipping case
ANTI-THEFT SECURITY
• Compatible with Kensington ® Microsaver
REGULATORY APPROVAL
• UL/CSA/IEC 60950 (3rd edition)
• FCC Class A, CE, CCC (pending)
• This product conforms to all relevant
European directives, standards, safety,
health and environmental concerns
WARRANTY
• Limited 3 years parts and labor
(excluding lamp)
• Lamp warranty 120 days or 500 hours
(whichever comes first)
The Christie LX25a’s small, sleek profile
