Operating instructions M3G084-FA33-82
Translation of the original operating instructions
3.2 Nominal data
Motor M3G084-FA
Phase 1~
Nominal voltage / VAC 230
Nominal voltage
range / VAC 200 .. 277
Frequency / Hz 50/60
Type of data definition ml
State prelim.
Speed / min -1 3000
Power input / W 621
Power output / W 503
Current draw / A 2.7
Rated torque / Ncm 160
Min. ambient temperature
/ °C -25
Max. ambient temperature
/ °C 40
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 6.8 kg
Size 84 mm
Material of electronics
housing Die-cast aluminium
Housing material Die-cast aluminium
Direction of rotation Counter-clockwise, seen on shaft
Type of protection IP 55
Insulation class "B"
Humidity class F3-1
Mounting position Any
Cooling bore / aperture Rotor-side
Operation mode S1
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 10 mA
- Output 20 VDC, max. 50 mA
- Output for slave 0-10 V
- Input for sensor 0-10 V or 4-20 mA
- Alarm relay
- Motor current limit
- PFC, active
- RS485 ebmBUS
- Soft start
- Control input 0-10 VDC / PWM
- Control interface with SELV potential
safely disconnected from the mains
- Over-temperature protected
electronics / motor
- Line undervoltage / phase failure
detection
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Electrical leads Via terminal box
Motor protection Thermal overload protector (TOP) wired
internally
Protection class I (if protective earth is connected by
customer at the connection point of the
housing)
Product conforming
to standard EN 61800-5-1; CE
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
3.6 Electromagnetic compatibility
EMC interference
immunity Acc. to EN 61000-6-2 (industrial
environment)
EMC harmonics Acc. to EN 61000-3-2/3
EMC interference
emission Acc. to EN 61000-6-4 (industrial
environment)
