Operating instructions

R2D225-AG02-10

Translation of the original operating instructions

3. TECHNICAL DATA

3.1 Product drawing

All measures have the unit mm.

Centrifugal impeller (sheet steel, galvanised)

Centrifugal impeller (sheet steel, rust- and acid-resistant)

3.1

yellow

3.2

green

3.3

white

3.4

brown

3.5

blue

3.6

black

M4 screw for fastening earth conductor
Screw depth max. 5 mm

Item no. 10128-5-9970 · ENG · Revision 82598 · Release 2014-10-13 · Page 4 / 9
