Operating instructions R3G140-AV03-02
Translation of the original operating instructions
3.2 Nominal data
Motor M3G055-CF
Phase 1~
Nominal voltage / VAC 230
Frequency / Hz 50/60
Speed / min -1 1800
Power input / W 66
Current draw / A 0.5
Min. ambient temperature
/ °C -25
Max. ambient
temperature
/ °C 60
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 1.24 kg
Size 140 mm
Surface of rotor Thick layer passivated
Material of electronics
housing Die-cast aluminium
Material of impeller Sheet steel, galvanised
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44
Insulation class "B"
Humidity class F3-1
Mounting position Any
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 1.1 mA
- Tach output
- Motor current limit
- Soft start
- Control input 0-10 VDC / PWM
- Control interface with SELV potential
safely disconnected from the mains
- Over-temperature protected motor
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Motor protection Thermal overload protector (TOP) wired
internally
Cable exit Variable
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC; EAC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
3.6 Electromagnetic compatibility
EMC interference
immunity Acc. to EN 61000-6-2 (industrial
environment)
EMC harmonics Acc. to EN 61000-3-2/3
EMC interference
emission Acc. to EN 61000-6-3 (household
environment)
Item no. 51075-5-9970 · Revision 82598 · Release 2014-05-08 · Page 5 / 10
