Operating instructions
R3G140-AV03-02
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Accessory part: Inlet nozzle 09576-2-4013, not included in the standard scope of delivery
2
Depth of screw max. 6 mm
3
Depth of screw max. 6 mm
4
Connection line PVC 3G 0.5 mm², 3 x brass lead tips crimped
5
Connection line PVC 4 x 0.25 mm²; 4 x brass lead tips crimped
