Operating instructions D4D225-FH02-01
Translation of the original operating instructions
3.2 Nominal data
Motor M4D094-LA
Phase 3~ 3~ 3~
Nominal voltage / VAC 400 400 440
Connection Y Y Y
Frequency / Hz 50 60 60
Type of data definition fa fa fa
Valid for approval /
standard CE CE CE
Speed / min -1 1300 1350 1410
Power input / W 950 1320 1460
Current draw / A 1.82 2.4 2.4
Min. back pressure / Pa 0 0 0
Min. ambient temperature
/ °C -40 -40
Max. ambient
temperature
/ °C 85 40 40
Starting current / A 4.6 4
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 39.6 28.2 35.2
Efficiency grade N 48.4 37 44
Power input P e / kW 0.4
Air flow q v / m³/h 1805
Pressure increase total p sf / Pa 319
Speed n / min -1 1425
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 15.6 kg
Size 225 mm
Material of impeller Sheet steel, hot-galvanised
Housing material Sheet steel, hot-galvanised
Motor suspension Motor anti-vibration mounted on both sides
Direction of rotation Clockwise, seen on rotor
Type of protection IP 20
Insulation class "F"
Humidity class F0
Mounting position Any
Condensate discharge
holes None, open rotor
Operation mode Continuous operation (S1)
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Motor protection Thermal overload protector (TOP)
brought out
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60034-1 (2004); CE
Approval CCC; EAC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
