4.4 Connection screen
Three-phase motor
Y
Star connection
Δ
Delta connection
L1
black
L2
black
L3
black
V2
black
U2
black
W2
black
PE
green / yellow
Item no. 10889-5-9970 · Revision 82891 · Release 2014-03-27 · Page 7 / 9
