3. Using wrench to tighten all corners
2.6 HOOK-UP CABLE
Figure 2 shows the wiring connections necessary to attach the platform to the read-out instrument. The
color code and function are as noted. Consult read-out manual for the required information for its hook-
up.
(Most scales are shipped with mating connector for easy hook-up to the instrument supplied)
COLOR CODE FUNCTION
BLACK – EXCITATION
WHITE – SIGNAL
RED + EXCITATION
GREEN + SIGNAL
YELLOW SHIELD
FIG. 2
SECTION 3.0 OPERATION
Follow the instrument's manual for correct power-up instructions.
The C3600P and C7200P Ton Container Scales are relatively simple devices. Once the operation of the
instrument is understood, the ton containers are simply placed on the rollers that are provided. Listed are
a few helpful points to follow when using Eagle Microsystems scales.
1. Always place the ton container in the approximate center of the scale
2. Place the ton containers on the scale. Do not drop them. Although the scale is designed to
withstand impact loads, care should be taken to avoid accidents.
SECTION 4.0 TROUBLE SHOOTING
The following is a list of potential problems and likely cures.
1. Inaccurate but repeatable weight readings:
a. Adjust span on read-out (see instrument manual)
2. Blank or drifting display:
a. Consult the instrument manual.
b. Look for loose connection in hook-up cable at the instrument or in the Summing Box.
See Section 5.1
d. Look for moisture in the Summing Box
c.
Test for bad load cell (see section 5.2)
SECTION 5.0 SERVICING
5.1 Checking the connections to the Summing Box.
1. Locate the Summing Box on the bottom frame and remove the cover. (4 screws)
2. View and compare all connections to Figure 3.
