TECHNICAL SPECIFICATIONS
(Measurements taken using +4dBu balanced input where applicable)
INPUT IMPEDANCE
20KS (bal), 20KS (unbal)
MAXIMUM INPUT LEVEL
+21dBu
LINE INPUT CMR
Better than !40dB
(20Hz - 22KHz)
OUTPUT IMPEDANCE
100S
MAXIMUM OUTPUT LEVEL
+20dBu
BANDWIDTH
16Hz to 28KHz !1dB
NOISE
ref +4dBu
Wideband
(worst case)
22Hz - 22KHz
AV
!85dB
!90dB
DISTORTION
Typical Input
100Hz
1KHz
10KHz
Unity Gain
(+4dBu input, +19dBu output)
< 0.05%
< 0.05%
<0.05%
POWER REQUIREMENTS
115Volt or 230Volt at 50-60Hz, 15VA
FUSE RATING
T63mA for 230Volt, T125mA for 115Volt
CONFORMING TO IEC 127-2
FUSE TYPE
20mm x 5mm, Class 3 Slo-Blo, 250Volt
working
CASE SIZE
482mm (w) x 44mm (h) x 200mm (d)
WEIGHT (incl packaging)
3.2 Kgs
