Drawmer MX60 Pro Front End One - Manual (Page 11)

EQUALISER STAGE
L.F Cut/ Boost High-pass shelving filter providing up to 18dB of cut or
boost below the turnover frequency of 100Hz.
Mid Parametric
Frequency
Centre frequency of the mid-range parametric equaliser,
variable from 150Hz to 16KHz.
Bandwidth Bandwidth of mid-range parametric equaliser, variable from
0.3 to 3 octaves.
Cut/ Boost Controls the amount of mid-range cut or boost up to a
maximum of ±18dB.
H.F Cut/ Boost Low-pass shelving filter providing up to 18dB of cut or
boost above the turnover frequency of 4.25KHz.
E.Q In Switches the EQ section in and out of the signal path.
TUBESOUND
Drive Lo Sets the amount of overdrive in the low frequency range
(up to 350Hz).
Drive Mid Sets the amount of overdrive in the mid frequency range
(between 350Hz and 2KHz).
Drive Hi Sets the amount of overdrive in the high frequency range
(from 2KHz upwards).
Ts In Switches the Tubesound section in and out of the signal
path.
11
