Christie LX34
Specifications
(103-002001)
Automatic set-up and direct key access for major
functions make the Christie LX34 easy to use. With a wide array of input compatibility and latest progressive scan video processing, the
Christie LX34 produces life-like images from a variety of sources.
• 3500 ANSI lumens
• 90% brightness uniformity
• 900:1 full field
DISPLAY TECHNOLOGY
AND RESOLUTION
• 3 x 0.99" p-Si Active Matrix TFT
LCD panels
• True XGA 1024 x 768
• 8-bit color resolution offering 16.7 million
displayable colors
DYNAMIC SCALING
• Digital scaling of VGA through
SXGA resolutions
• Digital de-interlacing of STV, DTV
and HDTV formats
SCAN RATES
• Horizontal – 15 kHz to 100 kHz
• Vertical – 50 Hz to 100 Hz
PIXEL CLOCK
• 140 MHz max
VERTICAL LENS SHIFT
• From 10:0 up to 1:1 on axis
INPUT SIGNAL COMPATIBILITY
• VGA to SXGA (1280 x 1024)
• Multi-standard video decoder
• Horizontal and vertical scaling, all inputs
VIDEO DECODER
• Built-in multi-standard video decoder
(NTSC, NTSC4.43, PAL, PAL M, PAL N,
PAL 60, SECAM)
INPUTS, CONTROL &
NETWORKING
• RGB HD15 and mini-stereo audio
• DVI-I digital/analog RGB/YPbPr and
mini-stereo audio
• YPbPr RCAx3
• Composite video RCA and L/R audio
• S-Video mini-DIN
• RS232 control mini-DIN
• USB Type B
• RGB monitor output HD15
• Mini-stereo audio output
ADVANCED FEATURE SET
• 3D Digital Noise Reduction
• Power zoom and focus
• Motorized lens shift (up and down)
• Digital keystone correction,
± 40˚ vertical, ± 10˚ horizontal
• Digital zoom and pan (x 49)
GRAPHICAL USER INTERFACE
• Easy set-up and intuitive multi-language
on-screen displays (OSD)
• Direct key functions
• Choice of image aspect ratios
(4:3 or wide 16:9)
LAMP
• 250W UHP lamp
• User-replaceable lamp
• 1500 hours (typical) lifetime
POWER REQUIREMENTS
• Universal power: 100 - 240 VAC @ 50/60 Hz
• Power consumption: 350W typical
• Thermal dissipation: 1194 BTU/hr
• Operating temperature: 0 to 35˚ C (32 to 95˚ F);
Storage: -30 to 60˚ C (-22 to 140˚ F)
• Operating humidity: 20 to 80%
(storage: 0 to 90%)
• Acoustic noise level: 30dB in economy mode
• Fan control system (FCS) for whisper-quiet
operation
DIMENSIONS
• 17.2 lb (7.8 kg) including standard lens
• 11.9 W x 16.6 L x 6.3" H (excluding lens)
• 302 W x 422 L x 162mm H) (excluding lens)
STANDARD ACCESSORIES
• User manual
• Computer cable
• Mouse control cable
• Lens cover
• Line cord x 2 (UL and European)
Compact and flexible, the
Christie LX34 delivers bright, bold
images in a sharable resource.
OPTIONAL ACCESSORIES
• Medium throw 1.2-1.6:1 zoom lens
• Long throw 2.1-3.4:1 zoom lens
• Lamp module
• Ceiling mount
• Shipping case
• ChristieNET™ connectivity for monitoring
and control
ANTI-THEFT SECURITY
• Compatible with Kensington ® style
security mechanisms
REGULATORY APPROVALS
• UL/CSA/IEC 60950 (3rd edition)
• FCC Class B, CE
• This product conforms to all relevant
European directives, standards, safety,
health and environmental concerns
WARRANTY
• 3 years parts and labor (excluding lamp)
• Lamp: 120 days or 500 hours, whichever
comes first
For the most current specification information, please visit www.christiedigital.com
Corporate Offices
USA
10550 Camden Drive
Cypress, CA 90630
PH: 714-236-8610
FX: 714-503-3385
Toll free: 866-880-4462 (NA only)
[email protected]
CANADA
809 Wellington Street North
Kitchener, Ontario N2G 4Y7
PH: 519-744-8005
FX: 519-749-3136
Toll free: 800-265-2171 (NA only)
[email protected]
Worldwide Offices
UNITED KINGDOM
PH: +44 118 977 8000
FX: +44 118 977 8100
[email protected]
GERMANY
PH: +49 2161 664540
FX: +49 2161 664546
[email protected]
FRANCE
PH: +33 (0) 1 47 48 28 07
FX: +33 (0) 1 47 48 26 06
[email protected]
HUNGARY
PH: +36 (0)1 47 48 100
FX: +36 (0)1 47 48 452
SINGAPORE
PH: +65 6877 8737
FX: +65 6877 8747
[email protected]
SHANGHAI
PH: +86 21 6278 7708
FX: +86 21 6270 5816
[email protected]
BEIJING
PH: +86 10 6561 0240
FX: +86 10 6561 0546
[email protected]
JAPAN
PH: +81 3 3599 7481
FX: +81 3 3599 7482
[email protected]
Copyright 2005 Christie Digital Systems, Inc. All rights reserved. All brand names and product names are trademarks,
registered trademarks or tradenames of their respective holders. Canadian manufacturing facility is ISO 9001:2000 certified.
Performance specifications are typical. Due to constant research, specifications are subject to change without notice.
Printed in Canada. 1344
