Cavity

Cartridge

Fuse

Mini

Fuse

Description

1

40 Amp

Green

Power Top Mod-

ule – If Equipped

2

20 Amp

Yellow

AWD Module

3

10 Amp

Red

Battery Feed –
Center High
Mounted Stop
Light (CHMSL)/
Brake Switch

4

10 Amp

Red

Battery Feed –
Ignition Switch

5

20 Amp

Yellow

Trailer Tow – If
Equipped

6

10 Amp

Red

Ignition Off Draw
(IOD) – Power
Mirror Switch/
Climate Controls

Cavity

Cartridge

Fuse

Mini

Fuse

Description

7

30 Amp

Green

Ignition Off Draw
(IOD) Sense 1

8

30 Amp

Green

Ignition Off Draw
(IOD) Sense 2

9

40 Amp

Green

Battery Feed –
Power Seats – If
Equipped/PZEV
Air Pump – If
Equipped

10

20 Amp

Yellow

Battery Feed –
Cabin Compart-
ment Node (CCN)

11

15 Amp

Lt Blue

Selectable Power
Outlet

12

20 Amp

Yellow

7

MAINTAINING YOUR VEHICLE

389
