Introducing the Olympus Accura View
Zoom 120, an incredibly easy-to-use
camera that’s part of our exciting new
Accura line-up. Featuring an all-new Smart
Viewfinder that gives you a bigger, brighter,
clearer view of your subject, it makes
photography more fun than over. And to
match the shooting ease of its new
viewfinder, the Accura View Zoom 120
features the power and flexibility of a
38~120mm 3.2x zoom lens.
ACCURA VIEW ZOOM 120 Names of Parts
Shutter release button
Flash mode button
______ Selftimer button
Mid-roll rewind button
Viewfinder________
Diopter adjustment dial
Date/time indicator
Battery compartment cover
Back cover
Quartz Date mode buttons
Tripod socket
Viewfinder Display & LCD Panel
Close-up
Battery check
(orange)
mark (orange)
Shutter release
indicator
(green)
@
_l
t
__________
Autofocus
mark (red)
Flash modes
Exposure counter
Z f O
Main Specifications
Type:
Full-automatic 35mm autofocus lens-shutter camera with built-in 38~120mm lens.
Film format:
35mm standard DX-coded film (24 x 36mm).
Olympus lens 38~120mm zoom, F3.7~10.8, 7 elements in 6 groups.
Programmed electronic shutter.
Viewfinder:
Real-image zoom viewfinder (with in-focus indication provided autofocus mark,
close-up correction mark, flash indicator and shutter release indicator).
Focusing:
Active-type autofocus system. Focus lock possible. Shutter release locks to warn
when inside minimum working distance. Focusing range — 2.6 ft.~^ (infinity).
Exposure
control:
Programmed automatic exposure control.
Auto exposure range — EV3.8~EV12.0 at wide angle; EV6.9~EV15.0 at telephoto.
Electronic selftimer with approx. 12-sec. delay.
Film speed
Automaticsettingwith DX-coded filmwith ISO50, 100, 200,400,800, 1600and 3200.
range:
For non DX-coded film and film with less than ISO 50, film speed is set to ISO 100.
Film loading:
Automatic loading.
Film advance:
Automatic film winding.
Film rewind:
Automatic film rewind. Rewind possible at any point with mid-roll rewind button.
Flash:
Built-in flash. Recycling time — Approx. 0.5~4 sec. (at normal temperature with
new battery). Flash working range — 2.6~17.4 ft. at wide angle and 2.6~5.9 ft. at
telephoto with ISO 100 color negative film; 2.6~34.8 ft. at wide angle and
2.6~11.8 ft. at telephoto with ISO 400 color negative film.
Flash modes:
Auto, <#>Red-Eye Reducing, Off, V Fill-In (forced activation)^ Night Scene
and
[§
Red-Eye Reducing Night Scene.
Power source:
One 3V lithium battery (DL123A or CR123A).
Dimensions:
5.1 (W) x 2.9 (H) x 2.3 (D) in. (without protrusions).
Weight:
10.4 oz. (without battery).
Specificaitons for Date Unit
Data coding:
Year-month-day, day-hour-minute, no data, month-day-year and day-month-year.
Automatic calendar system:
Up to year 2049.
Power source:
One 3V coin-type lithium battery (CR2025).
Battery life:
Approx. 3 years (approx. 40,000 imprints).
•Appearance and specifications are subject to change without notice.
