9
FP2603, FP2604
www.chpower.com
Ref.
No. Description
Part
No. Qty.
1 Accessory Tray l 1
2 On/Off Switch FP205129AV 1
3 Shroud l 1
4 Screw n 4
5 Shroud Insert l 1
6 Screw l 4
7 Screw n 2
8 Pump/Motor Assembly -- 1
9 Motor Cover s 1
10 Motor Cover Isolator s 1
11 Screw -- 1
12 Wire Clip FP202823AV 1
13 Exhaust Tube Assembly FP202839AV 1
14 Wire (Pressure Switch to
Power Switch) FP209523AV 1
15 Power Cord t 1
16 Wire Clip/Strain Relief t 1
17 Screw -- 1
18 Washer with Teeth -- 1
19 Terminal -- 1
20 Outlet Gauge FP204013AV 1
Ref.
No. Description
Part
No. Qty.
21 Tank Gauge FP204012AV 1
22 Regulator and Manifold
Assembly FP018300AV 1
23 Safety Valve V-215100AV 1
24 Check Valve Assembly FP209532AV 1
25 Check Valve
26 Poppet -- 1
27 Spring -- 1
28 Pressure Switch FP018400AV 1
29 Tank -- 1
30 Drain Valve D-1403 1
31 Rubber Foot u 3
32 Screw n 2
REPLACEMENT PARTS KITS
l Shroud Kit FP018500AV
n Fastener Kit FP018600AV
s Motor Cover Kit FP018700AV
t Powercord with Strain Relief FP209534AV
u Rubber Foot Kit FP202836AV
-- Not available
Replacement Parts List
