SECTION 13: SPECIFICATIONS^
LX420
LX460
Capacities
Fuel Tank
3.0 gal. (11.4 liters)
3.0 gal. (11.4 liters)
Engine Crankcase (w/ filter)
50.75 oz. (1.5 liters)
50.75 oz. (1.5 liters)
Variable Speed Transmission
Forward Speed
0 - 5.2 mph (8.2 km/h)
0 - 5.2 mph (8.2 km/h)
Reverse Speed
0 - 2.3 mph (3.7 km/h)
0 - 2.3 mph (3.7 km/h)
Engine (Air-cooled, 4-cycle)
Make
Kohler Courage
Kohler Courage
Model
SV540
SV600
Cylinders
Single
Single
Bore
3.50 in. (89 mm)
3.70 in. (94 mm)
Stroke
3.38 in. (86 mm)
3.38 in. (86 mm)
Displacement
32.6 cubic in. (535 cc)
36.4 cubic in. (597 cc)
Power @3600 RPM
18 HP (13.4 kW)**
20 HP (14.9 kW)**
Maximum Torque
32.1 ft. lb. (43.5 N-m)
@ 2200 RPM
36.9 ft. lb. (50.0 N-m)
@ 2200 RPM
Compression Ratio
8.5:1
8.5:1
Engine Speed (governed)
3375 RPM
3375 RPM
Low Speed
2150 RPM (± 75 RPM)
2150 RPM (± 75 RPM)
Spark Plug Gap
.030 in. (.76 mm)
.030 in. (.76 mm)
Electrical System
System Voltage
12-volt Negative Ground
12-volt Negative Ground
Battery
190 CCA (sealed)
190 CCA (sealed)
Alternator
15 Amp Regulated
15 Amp Regulated
Fuse (automotive type)
20 Amp
20 Amp
Headlights
Incandescent
Incandescent
Brakes
Single Disc (Dry)
Single Disc (Dry)
Turf Tires
Front (inches)
1 5 x 6 x 6
1 5 x 6 x 6
Rear (inches)
20
X
8
X
8
20
X
8
X
8
Dimensions
Cutting Width, Deck
42 in. (106.7 cm)
46 in. (116.8 cm)
Wheelbase
46 in. (116.8 cm)
46 in. (116.8 cm)
Length, overall
68 in. (172.7 cm)
68 in. (172.7 cm)
Width, overall
45 in. (114.3 cm)
48 in. (127.9 cm)
Height, overall
43 in. (109.2 cm)
43 in. (109.2 cm)
Ground Clearance
4.5 in. (11.4 cm)
4.5 in. (11.4 cm)
Turning Radius
18 in. (46 cm)
18 in. (46 cm)
Weight (approximate)
498 lb. (225.9 kg)
501 lb. (227.25 kg.)
Toro
reserves the right to change product specifications, design, and standard equipment without notice and without incurring obligation
/ affected by, but not limited to, accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed and ambient 33
operating conditions (temperature, humidity, and altitude).
