FEATURES

AND BENEFITS

1. Reservoir Cover

Flips back for easy filling. Removable

for easy cleaning. A Safety Interlock
System prevents operation of the unit if
the Reservoir Cover is open.

2. Reservoir Cover Release Button

3. Showerhead (not shown)

Distributes water evenly over coffee,
reducing temperature loss as water
passes through grounds.

4. Control Panel

See detailed drawing, page 7.

5. Filter Basket Compartment

see detailed drawing, page 6.
Contains:

Filter Basket
Filter Basket Cover

Cuisinart Gold Tone Commercial

Style Filter

6. Filter Basket Door Release Button

7. Brew Pause (not shown)

Stops flow of coffee from basket when
carafe is removed from heater plate
so a cup can be poured in mid-brew,
if desired.

8. Heating Plate

Scratch resistant with nonstick coating.

9. Carafe

The easy-pour, no-drip 12-cup carafe has
an ergonomic handle and brewed coffee
markings for two to twelve cups.

10. Cord Storage (not shown)

11. Measuring Scoop and Brush

(not shown)

12. #4 Basket Paper Filters included

(not shown)
