Securing Child in Vehicle with

Shoulder Belt Positioning Clip

The shoulder belt MUST lay

across child’s shoulders in

red zone as shown.

If shoulder belt lays outside

this zone, the shoulder belt

positioning clip MUST be

used.

To attach clip to booster

seat:

1. Insert the loop end of strap around verticla bar

on rear of seat as shown in (Ql. The shoulder belt

positioning clip MUST be attached onto the vertical

bar of the base closest to where the vehicle shoulder

belt lays across the child.
