Installation Manual Double DIN Kit Honda Civic Hybrid 2006->
1 Disconnect the negative battery
terminal to prevent an accidental
short circuit.
2 Unclip and remove the panel below
the steering wheel. (Figure A)
3 Remove the (1) Phillips screw
exposed on the lower left side of the
panel above the steering wheel and
around the instrument cluster.
(Figure B)
4 Unclip and remove the panel around
top of steering wheel and instrument
cluster. (Figure C)
5 Remove panel inside pocket below
radio and climate controls then
remove (2) 8 MM screws facing up
behind panel. (Figure D)
6 Unclip and remove radio/climate
control assembly. (Figure E)
7 Remove (3) Phillips screws securing
the a/c vent to the radio/climate
control panel. (Figure F)
8 Remove the (4) Phillips screws
securing the climate control to the
radio/climate control panel.
(Figure F)
9 Remove the (2) Phillips screws
securing the hazard switch to the
radio/climate control panel.
(Figure F)
10 Remove the (2) Phillips screws
securing the passenger air bag
on/off light to the radio/climate con­
trol panel. (Figure F)
All installation work must be performed by a qualified professional installer only.
The manufacturer/dealer is not liable for any kind of incidentia! or indirect damages.
